Flameshow is a terminal Flamegraph viewer.

• Renders Flamegraphs in your terminal
• Supports zooming in and displaying percentages
• Keyboard input is prioritized
• All operations can also be performed using the mouse.
• Can switch to different sample types

Flameshow is written in pure Python, so you can install via pip:

pip install flameshow

But you can also run it through nix:

nix run github:laixintao/flameshow
# Or if you want to install it imperatively:
nix profile install github:laixintao/flameshow

View golang's goroutine dump:

$ curl http://localhost:9100/debug/pprof/goroutine -o goroutine.out
$ flameshow goroutine.out

After entering the TUI, the available actions are listed on Footer:

• q for quit
• h j k l or ← ↓ ↑ → for moving around, and Enter for zoom in, then Esc for zoom out.
• You can also use a mouse, hover on a span will show it details, and click will zoom it.

This project is built on flamegraph-textual.

The flamegraph renderer is available as a separate package:

pip install flamegraph-textual

As far as I know, there is no standard specification for profiles. Different languages or tools might generate varying profile formats. I'm actively working on supporting more formats. Admittedly, I might not be familiar with every tool and its specific format. So, if you'd like Flameshow to integrate with a tool you love, please feel free to reach out and submit an issue.

• Golang pprof
• Brendan Gregg's Flamegraph
• Python Austin
• Speedscope (evented and sampled profiles)
• Google Trace Event format

If you want to dive into the code and make some changes, start with:

git clone git@github.com:laixintao/flameshow.git
cd flameshow
pip install poetry
poetry install

This project is proudly powered by textual.
